User-Friendly Long-Life Steam Station Iron with Automatic Alarm Function for Dry Cleaners

Customization:	Available
Function:	Steam Boilers
Fuel:	Electric Heating

⚡ Basic Info.

Model NO.	Electric steam generator	Installation	Packaged Boiler
Structure	Fire Tube	Media	Steam
Water Circulation	Natural Circulation	Drum Placement	Vertical Boiler
Manufacturing Level	B	Burning Style	Chamber Combustion
Usage	Industrial	Working Efficiency	99%
Control Mode	PLC	Warranty Period	2 Years
Certificate	CE	Delivery Time	15 days
Working Pressure	7bar, 10bar	Working Life	15 years

📦 Product Description

With electric energy as energy source, no noise and no pollution. Using high quality heating tube, the surface heat load is low and the thermal efficiency is high. Aluminum silicate fiber blanket is used for multi-layer insulation and aluminum-zinc plated color coated sheet is used for outer packaging. Living packaging caps are used at both ends to facilitate installation and maintenance.

📊 Product Parameters

Model	Unit	LDR-0.03
Rated steam capacity	kg/h	30
Rated pressure	Mpa	0.4/0.7
Steam temperature	ºC	151/170
Water capacity	L	23
Design thermal efficiency	%	98%
Motor power	Kw/h	24
Heating tube power	Kw/h	12
Product size (LWH)	mm	410650960

🛠 Technical Information

Adopt high quality electric heater with low surface load and long working life.
Control electric heating element by marching type input method to reduce grid impact.
Automatic heating element adjustment based on temperature and load to save energy.
Manual input or shutdown options for flexible heat productivity.
Advanced centrifugal glass fiber floss for multi-layer heating insulation.
Boiler limit water level protection with automatic power cut-off and alarm.
No noise, no pollution, and convenient installation.
PLC control technology: overheat, overload, short circuit, and water shortage protection.

🌐 Application Scope

Washing & Ironing: Dry washer, dryer, ironing machine, electric iron.
Packaging: Labeling machine, marking machine.
Bio-chemical: Fermentation tank, reactor, sandwich pot, blender.
Food Machinery: Tofu machine, steam box, sterilization tank, packaging machines.
Others: Steam cleaning, hot water supply for hotels/schools, concrete curing, sauna.

✨ Main Products & Cases

🏢 Profile & Quality

Founded in 2010, the enterprise specializes in researching, developing, designing, and manufacturing industrial boilers and pressure vessels. With a strong R&D team including dozens of engineers and technicians, the production facility covers over 70,500 square meters. The equipment has been exported to more than 30 countries worldwide, gaining a high reputation for reliability and efficiency.

📜 Certifications

❓ FAQ

How quickly can I get the best price?

To provide an accurate quote, please specify the required boiler capacity, the fuel source you intend to use, and your required steam pressure. This allows us to confirm the most suitable model immediately.

What is the expected service life of the steam generator?

With proper operation and regular maintenance, our electric steam generators are designed to last for more than 20 years.

Why should I choose this electric boiler?

Our boilers feature Class A production qualifications, 100% X-ray inspection on welds, and undergo rigorous water pressure testing to ensure maximum safety and standard working performance.

Are customized products available?

Yes, we offer customization for colors, logos, packaging, and specific design requirements to meet your industrial needs.

What safety features are integrated into the system?

The system utilizes PLC control technology for fully automatic operation, including protection against overheat, overload, short circuits, water shortage, and electric leakage.

What is the thermal efficiency of the generator?

The design thermal efficiency of our electric steam generators exceeds 98%, ensuring minimal energy waste and high productivity.
