The Rolling Ball Mill is specialized powder milling equipment engineered for ultra-fine grinding and mixing, suitable for laboratory use as well as small-scale batch production. With its sleek modern design, compact construction, and high efficiency, it serves as an excellent choice for scientific research and experimental work.
When the machine operates, the grinding media and materials within the cylinder are rotated to a specific height. Due to gravity, they fall along the tube wall, crushing materials through impact, friction, and shear forces generated by the rolling and sliding of the media.
Widely used in electronics, magnetic materials, biological medicine, ceramic glazes, metal powders, non-metallic minerals, and the development of new materials.
| Category | Dimensions (mm/kgs) | Model No. | Motor Power (kW) | Voltage | Rotate Speed (rpm) |
|---|---|---|---|---|---|
| Lab Model | 730*415*260/35 | QM-5 | 0.37 | 220V-50Hz | 60-570 |
| 2 workstation | 950*480*685/72 | GQM-2-5 | 0.75 | 220V-50Hz | 50-410 |
| 4 workstation | 950*660*690/70 | GQM-4-5 | 0.75 | 220V-50Hz | 50-410 |
| Materials Category | Recommended Mill Jars |
|---|---|
| Soil / Pure Materials | Agate mill jar |
| Metal & Nonmetal | Zirconia mill jar |
| High Hardness (Diamond) | Tungsten carbide jar |
| Strong Acid/Alkali | PTFE mill jar |
Established in 2011 with CE, ISO 9001, and SGS certifications.
Long-term quality guarantee for all main machines.
Devices do not require assembly and are simple to operate.
Shipment within 3-7 working days with items always in stock.
24/7 support via phone and email. Friendly English manuals and operation videos provided. Machines are properly adjusted before dispatch for immediate use.
