High Quality Roller Ball Mill Two-Station Gms-2-15 for Metal/Minerals Powder Grinding

1 / 5

High Quality Roller Ball Mill Two-Station Gms-2-15 for Metal/Minerals Powder Grinding

Still deciding? Get samples of $ !

Order Sample

Send Inquiry

Product Description

Basic Information

Model NO.	GMS-2-15
Object	Rice, Crop, Solid, Mud
Application	Laboratory
Disc(Wheel) Type	Grinding Disc
Material	Steel
Working Style	Roller Ball Mill
Disc Diameter	100-400 mm
Variable Speed	With Variable Speed
Motor Power	1.1kw
Main Roller Speed	40-340rpm
Effective Length	762mm
Max Load Capacity	80kgs (Single Tank)
Transport Package	Wooden Cases

Product Description

High Quality Roller Ball Mill (Two-station GMS-2-15) for Metal/Minerals Powder Grinding. This roller ball mill features a novel appearance and advanced structure, optimized for speed and ease of use. The grinding jar is supported by rubber rollers, creating a tilting motion that disperses materials effectively for optimal results.

Equipped with a digital display time controller, users can set precise working durations, including pause and cumulative timing functions. As the cylinder rotates, grinding media and materials are lifted and dropped in a parabolic motion, utilizing friction and impact to achieve superior mixing and grinding effects.

Detailed Photos

Product Features

Multi-Sample Capability: Multiple tanks can be used simultaneously for intermittent or continuous grinding.

Precision Timing: Digital operation allows for customized timing based on specific material requirements.

High Efficiency: Specifically designed for fine grinding with high crushing efficiency for various materials.

Durable Build: Load-bearing rubber rollers are made of specialized, wear-resistant materials for long-term durability.

Product Parameters

Two-station Roller Ball Mill	Dimensions: 940550680mm
	Motor Power: 1.1kw
	Inverter Power: 1.1kw/220v
	Main Roller Speed: 40-340rpm
	Effective Roller Length: 762mm
	Max Single Tank Load: 80kgs

Expertise & Infrastructure

As a high-tech enterprise specializing in powder equipment, we focus on research, development, and production of ball mills, crushers, and mixing equipment. Our planetary and roller ball mills are essential for fine grinding, small sample preparation, and new product development across industries such as geology, metallurgy, electronics, and ceramics. All products meet ISO9001 and CE standards.

Certifications

Frequently Asked Questions

1. What models of roller ball mill machines are available? We offer a wide range of models including GMS-2-5, GMS-2-15, GMS-2-20, GMS-4-5, GMS-4-15, GMS-4-20, GMS-8-5, and GMS-8-15 to suit various laboratory needs.

2. What are the primary features of this machine? The machine features a novel design, advanced internal structure for high efficiency, and a user-friendly digital control system for precise grinding operations.

3. What grinding materials and jar sizes are supported? Available materials include zirconia, agate, stainless steel, alumina, and more. Jar volumes range from 5L to 20L, with ball sizes available from 1mm to 20mm.

4. What are the shipping and delivery options? Customers can choose between air freight, sea freight, or Express door-to-door delivery. Standard delivery typically occurs within 10 working days after payment.

5. Which materials can be processed by the GMS-2-15? This roller ball mill is ideal for grinding rice, crops, solid samples, mud, minerals, and metal powders in laboratory settings.

6. Is the speed of the machine adjustable? Yes, the machine comes with an inverter and variable speed control, allowing the main roller speed to be adjusted between 40 and 340 rpm.
